    Anticorrosive 230VDC 80A MPPT Solar Charge Controller Discharging Protection

    Ask Lasest Price
    Brand Name : Sunchonglic
    Model Number : MPPT-80A(12V-96V)
    Price : US $11.15-178.34
    Payment Terms : T/T
    Supply Ability : 100000pcs/mon
    Delivery Time : 20-60 work days
    • Product Details
    • Company Profile

    Anticorrosive 230VDC 80A MPPT Solar Charge Controller Discharging Protection

    230V DC 12V 24V 36V 48V 60V 72V 84V 96V 80A MPPT Solar Charge Controller

    >>>Product Description


    What is feature of 230V DC 12V 24V 36V 48V 60V 72V 84V 96V 80A MPPT solar charge controller?

    1.Charging current can be manually regulated

    2.Multiple charging and discharging protections

    3.Designed for 12V/24V/36V/48V/60V/72V/84V/96V DC

    4.Max PV array open circuit voltage 230V DC

    5.Support Max 96V lead acid battery

    6.Support Max 45 cells LiFePO4



    >>>Product Specifications

    Model
    80A/100A
    Charging Mode
    MPPT automatic maximum power tracking
    Charging Method
    MPPT tracks maximum power,fast charge,balanced charge,and float charge
    Battery type
    Lead Acid
    (12V/24V/36V/48V/96V Auto+Adjustable 12V/24V/36V/48V/60V/72V/84V/96V)
    Gel
    12V/24V/36V/48V/60V/72V/84V/96V
    LifePo 4
    Single voltage 3.2* numbers of strings
    (2 strings-45 strings adjustable)
    Li-ion
    Single voltage 3.7* numbers of strings (2 strings-45 strings adjustable)
    USER
    Adjustable limit voltage for equal charge, float charge and DC discharge:8V-170V
    With lithium battery activation function
    With photovoltaic input,there is charging voltage(activate lithium battery),can be used without battery DC output
    PV maximum open circuit input voltage
    0-230V
    The charging current is adjustable
    0-80A
    0-100A
    Start charging
    PV voltage is greater than + 3V of battery voltage(low current charging on rainy days)
    Direct charging current output function
    DC continuous output 100A
    Temperature compensation
    According to the temperature of the battery,the charging voltage and current are automatically compensated to prolong the battery life
    Display communication
    LCD display with touch button:(generating capacity/photovoltaic voltage/battery voltage/charging current/power/operation status)
    Chinese and English display
    Setting:(battery type,charging current,return to factory)
    8-pin RS485 communication interface(operation status and setting can be queried)
    Working environment temperature
    -20℃-40℃
    Protection level
    IP21
    Altitude
    0-3000m
    Product size
    /

    >>>Our Factory

    Sunchonglic specializes in premium solar solutions, including inverters, AGM/GEL battery systems, and MPPT charge controllers, ensuring reliable energy performance. Our technical team offers customized configurations, installation guidance, and responsive after-sales support!

    >>>Production Process



    >>>FAQ


    Q1. Are you the factory manufacturer?
    A1.With over two decades of expertise, we specialize in manufacturing and developing innovative solar

    photovoltaic solutions as an original equipment producer. Our product portfolio encompasses hybrid

    inverters, power conversion systems, charge controllers, energy storage solutions, and comprehensive

    solar power systems designed for optimal performance
    Q2.How to select a suitable products?
    A2.Tell us your demand, we will recommend a suitable one to you.
    Q3. What is your payment methods?
    A3. We accept T/T,Trade Assurance,etc.
    Q4. What’s the price terms can you offer for us?
    A4. We can accept EXW, FOB, CIF and so on.
    Q5. Where is your main market for your products?
    A5. Most of our Sunchonglic brand products are exported to Southeast Asia, Africa and
    Mid East etc.


    Our offerings have earned widespread recognition and trust from clients globally, effectively

    adapting to evolving economic and social demands . We extend a warm invitation to both new

    and existing partners worldwide to collaborate with us, fostering mutually beneficial relationships

    that drive shared success !
