    80A Mppt Solar Charge Controller Overcharge Protection 48v Solar Charge Controller

    Ask Lasest Price
    Brand Name : Sunchonglic
    Model Number : MPPT-80A(12V-60V)
    Price : US $11.15-178.34
    Payment Terms : T/T
    Supply Ability : 100000pcs/mon
    Delivery Time : 20-60 work days
    • Product Details
    • Company Profile

    80A Mppt Solar Charge Controller Overcharge Protection 48v Solar Charge Controller

    80A Solar Mppt Charge Controller Solar Mppt Charger 12V 24V 48V 60V

    >>>Product Description


    What is feature of 80A solar mppt charge controller solar mppt charger 12V 24V 48V 60V?

    1.Built-in Lithium battery activation function

    2.Off-grid solar system charging and discharging

    3.Innovative maximunm power point tracking technology can significantly improve the energy utilization rate of the solar system,with conversion efficiency of up to 97%.

    4.Quickly scan the entire I-V curve,and efficiently track the maximum power point.

    5.Three types of lead-acid batteries,sealed,colloidal,and open type,and lithium battery series are optional.

    6.With automatic protection of overcharge,overdischarge, overload and short circuit.



    >>>Product Specifications


    Model60A/80A
    Charging ModeMPPT automatic maximum power tracking
    Charging MethodMPPT tracks maximum power,fast charge,balanced charge,and float charge
    Battery TypeLead Acid(12V/24V/48V/60VAuto+Adjustable 12V/24V/48V/60V)
    Gel12V/24V/48V/60V
    LifePo 4Single voltage 3.2* number of strings (2 strings-45 strings adjustable)
    Li-ionSingle voltage 3.7* number of strings (2 strings-45 strings adjustable)
    USERAdjustable limit voltage for equal charge,float charge and DC discharge:8V-170V
    With lithium battery
    activation function
    With photovoltaic input,there is charging voltage (activate lithium battery),
    can be used without battery DC output
    PV maximum open
    circuit input voltage
    0-180V
    The charging current
    is adjustable
    0-60A
    0-80A
    Start chargingPV voltage is greater than+3V of battery voltage(low current charging on rainy days)
    Direct charging
    current output
    function
    DC continuous
    output 40A
    Temperature
    compensation
    According to the temperature of the battery,the charging voltage and current are
    automatically compensated to prolong the battery life
    Working
    environment
    temperature
    -20'C~40℃
    Protection levelIP 21
    Altiude0~3000m
    Product size218x265x100mm

    >>>Our Factory

    As a professional manufacturer with decades of expertise in solar photovoltaic solutions, we specialize in developing solar power inverters, AGM/GEL battery chargers, and advanced solar charge controllers . Our Sunchonglic-branded products offer reliable energy conversion certified by CE, RoHS, and ISO9001 standards, ensuring optimal performance across residential and commercial applications .

    For detailed specifications or customized solutions, our technical team provides comprehensive pre-sales consultation and post-sales support . Contact us directly to explore our full product portfolio and discover how our solar innovations can power your sustainable energy needs.

    >>>Production Process



    >>>FAQ


    Q1. Are you the factory manufacturer?
    A1. We are doing the Solar Energy Photovoltaic Products for over 20 years.
    We are the original manufacturer and developer of advanced Solar Energy Photovoltaic
    Product,including hybrid solar inverter, power inverter,battery chargers,solar controller,
    and solar system,etc.
    Q2.How to select a suitable products?
    A2.Tell us your demand, we will recommend a suitable one to you.
    Q3. What is your payment methods?
    A3. We accept T/T,Trade Assurance,etc.
    Q4. What’s the price terms can you offer for us?
    A4. We can accept EXW, FOB, CIF and so on.
    Q5. Where is your main market for your products?
    A5. Most of our Sunchonglic brand products are exported to Southeast Asia, Africa and
    Mid East etc.


    Our products are widely recognized and trusted by our clients and can meet continuously
    changing economic and social needs.
    We would sincerely welcome new and old customers from over the world to visit and
    contact us for future business relationships and mutual success!
